CM1 MCCB Molded Case Circuit Breaker

CM1 MCCB
circuit breaker
CM1
molded case
Product description: CM1 series molded case circuit breaker is one of the breakers which is adopts international advanced design, manufacture technology to develop. The rated insulating voltage is 750V, suitable for AC 50
INQUIRY

CM1 series molded case circuit breaker is one of the breakers which is adopts international advanced design, manufacture technology to develop. The rated insulating voltage is 750V, suitable for AC 50/60Hz, rated working voltage 690V or below, rated working current is 12.5A to 1250A of circuit and used in distributing electric energy, and non-frequent breaking in the normal conditions, protecting the current & equipment from overload & under voltage, circuit breaker with rated frame current 400A or below, can be used in mouse cage motor’s non-frequent start, breaking during working, protecting motor from overload, short circuit & under voltage, the product conforms to IEC60947-2 standard.
